產品參數 (Parameters）：
型號
Model HX-Z5K HX-Z10K HX-Z15K HX-Z20K
額定功率
Rated voltage 1.5KW 3KW 7.5KW 11KW
額定電流
Rated power 15A 15A 42A 45A
額定磁場
Fixed magnetic field 5000GS 10000GS 15000GS 20000GS
輸出電壓
Output voltage 90V 200V 180V 180V
輸出電流
Output electricity current 15A-18A 15A-18A 42A-60A 45-62A
絕緣等級
Lnsulation rank F級 F級 F級 F級
處理能力
Processing capacity 5T-15T 10T-20T 20T-25T 25-30T
重量
weight 300KG 600KG 1000KG 1500KG
適用范圍（Application）：
本產品廣泛適用于去除陶瓷、化工、電子、食品等行業漿釉料中的鐵粉、微鐵粉、磁性物質。
This product,with function of removing iron poewer,micro iron
powder,magnetic substance and other materials,can beapplied in a variety
of settings:ceramic,mining,chemical.electronic and food industries…
typ.
產品特點 (Feature)：
※ 能耗低、磁場梯度高、磁場分布均勻、除鐵效果明顯。
※ 采用H級高溫電磁線，絕緣等級比過去提高5-10倍。
※ 全自動作業，無需人工操作，脫鐵方便快捷、更徹底。
※ 脫鐵采用振動電機輔助外加高壓水泵進行沖洗，脫鐵無死角、無殘留物。
※ 制動閥采用進口原料制造而成，無泄漏、低磨損、低流阻、低耗氣量。
※ 磁介網采用高效不銹鋼導磁片，最高磁場可達180000GS，斷掉勵磁線圈電源后，無殘留磁性，便于脫鐵。
Low energy consumption,high magnetic field gradient,ecen magnetic fisld distribution and obvious effort in eliminating.
The H levl high temperature electromagnetic wire is adopted.Its insulation rank is enhanced 5-10 times compared to the previous ones.
Completely automatic work,manual control isn’t demanded,eliminating iron in a fast,conveniet and more complete way with no iron powder remaining.
The vibration electrical machinery with the assistant of high-pressure water pump to wash is used for getting rid of iron without dead corner and residuum.
The brake valve is made up of the imported raw materials,no leaking,low block in flowing and low air consumption.
The highly effective stainless steel is used in making the magnetic screen.The highest magnetic field may reach 18000GS. When the power is off,the magnetic coils have no residual magnetism in favor of eliminating iron.
|
