適用范圍 (Fpplication)：
廣泛應用于食品、醫藥、化工、磨料、陶瓷、礦業、顏料、冶金、地質、國防、電子等行業的漿料、粉料、顆粒生產分級過濾等。
This product,with functions of producing,grading
and filtering the slip material,powder material and granules,can be widely applied in a variety of settings:food,medical,chemical,grinding compound,ceramics,mining,painting,metallurgical,national defense and electronic industres.
工作特點 (Features)：
※ 獨特的篩網結構設計、方便和快速更換細網
(僅需5-10分鐘)。
※ 篩機設計精巧和容易裝配，一人即可操作篩
機。
※ 有效篩面面積大、篩分效率高。
※ 可單層或多層（最多5層）使用、同時篩分
出不同顆粒。
※ 篩網壽命長、降低生產成本。
Unique sieve frame design for convenience and quick change of sieve(only 5 to 1 minutes required).
Exquisite design:the resulting simple and easy assembling and dismantling can be carried out by a single person.
Large sieving area and high performance form a machine of the same dimensions.
The use of monolayer or multilayer or multilayer(at most five) sieves ensures of screening different materials.
Screening mesh have an exceptionally long service life and keep down costs.
產品參數 (Paramenters)：
產品型號 電機功率 篩網直徑 外形尺寸篩網層數
HX-600-1S 750W 550mm 600*600*700 1
HX-800-1S 750W 760 mm 800*800*695 1
HX-1000-1S 1100W 930 mm 1000*1000*690 1
HX-1200-1S 1500W 1130 mm 1200*1200*850 1
HX-1500-1S 2200W 1430 mm 1500*1500*895 1
|
